An off-road forklift is an engineering vehicle that can load, unload, stack and transport cargo on slopes and uneven ground. An off-road forklift, also called a four-wheel drive forklift, is a type of internal combustion forklift. It is mainly used for urban construction sites, muddy roads, mountainous woodlands and other uneven roads, as well as loading and unloading of containers at docks and yards. It can be equipped with a variety of attachments such as buckets, grab forks, and clamps, which not only reduces the fatigue of manual operations, but also increases the speed of handling operations. It can move freely in sand, snow, muddy areas, slopes, etc. At the same time, it has a compact structure and can move flexibly in narrow spaces. The off-road forklift adopts a fully hydraulic electronically controlled gearbox, fully hydraulic steering, and pilot work to make the whole machine more flexible and lightweight. Compared with traditional diesel forklifts, it has better capabilities in all aspects.

Structure Features:

1. Off-road forklift truck driving tires are made of deep pattern and large width off-road tires, which can have good grip, anti-slip and stability under muddy road conditions such as construction sites and farms.

2. the cross-country forklift door frame adopts the widened design, and has a better view when using. Wide view frame improves work efficiency and work performance. Off-road vehicles work in harsh conditions and have a large impact, so we have strengthened the design of the gantry to make it more reliable.

3. the ground clearance is small, with special off-road tires. Four-wheel drive with anti-slip differential on the front axle. The design between the engine and the transmission is more compact. Able to work in harsh areas such as rough terrain, sand or mud. The front frame is provided with a fork working device and a driving front axle, and the rear frame is provided with a device and a driving rear axle. The rear frame is also provided with a power device connected with the driving front axle and the driving rear axle respectively, and the front frame and the rear frame are connected through an articulated device, and a steering cylinder is installed between them. Four-wheel drive increases the power of the forklift, so that the forklift can be loaded, unloaded, stacked and handling on the sand and rugged ground, with good off-road performance, through performance and large traction, and because there is no need to drive the front axle with a steering device, you can use the same drive axle as the drive rear axle, greatly reducing the cost of the vehicle.

4. the off-road forklift truck for the field muddy conditions, equipped with differential lock gearbox, when a driving wheel into the mud began to slip, the drive axle left and right half shaft into a rigid body, to achieve 100 self-locking, to achieve the drive wheel torque redistribution, so as to climb out of the mud pool. After climbing out of the mud pool, the self-locking function is unlocked to achieve normal driving. The off-road forklift truck is beautiful in shape, compact in structure, small in turning radius, light and flexible, can operate in a narrow space full hydraulic power steering, steering wheel and seat can adjust the Angle and relative position before and after, to meet the personalized requirements of the driver. Off-road forklift has high requirements for tire design. Reinforced tread base rubber to provide additional protection against collisions and punctures; The ultra-wide sidewall not only improves the durability of the tire, but also provides excellent impact resistance.

5. the role of the engine off-road forklift power device is to supply the forklift working device loading and unloading cargo and tire chassis operation required power.

6. wild forklift wide vision door frame, the driver has a wide Angle of view, so the forklift is very suitable for loading and unloading, stacking and short-distance transportation operations in the field and outdoors.

Application Scenario:

Chassis powerful off-road forklift truck, used in airports, docks, stations and other loading and unloading equipment. With the industrial practicality of ordinary forklifts, it can be said to be a powerful combination. The speed of off-road forklifts is higher than that of ordinary forklifts, which shows that its mobility is also unique in order to better adapt to the working environment. The body is wide, can carry irregular and wide goods; The gap from the ground is large, in order to facilitate crossing the obstacles on the site; The four-wheel drive function is to ensure the normal work in the muddy site, optimize the working device, high unloading, large digging force, high working efficiency and low fuel consumption.

Off-road forklift truck is suitable for loading and unloading materials in airports, docks, stations and other materials distribution centers with poor road conditions. It has the good mobility and off-road of ordinary off-road vehicles, and has the industrial practicality of ordinary forklifts, which can be said to be a powerful combination. The speed of off-road forklifts is higher than that of ordinary forklifts, which shows its maneuverability. On the other hand, the off-road forklift adopts all-wheel drive and off-road tires, so it can drive on mountains, beaches, sand, snow and muddy roads, showing good off-road performance.

Operation Characteristics:

1. Articulated steering, steering system is simple to operate, can easily turn a small corner.

2. The rear axle of the off-road forklift truck is fixed with the frame, and the front axle is vertically swung relative to the frame, which is conducive to the smoothness of the vehicle.

3. Large wheelbase and wheelbase spacing increase vehicle stability.

4. With good maneuverability, a variety of engine forms, at your choice.

5. Solid welding frame, increase the overall stability of the whole car, durable, not easy to damage.

6. Cross-country forklift double hydraulic cooling system, convenient cooling, rapid cooling.

Advantages Over Ordinary Forklifts:

1. The ordinary forklift is two-wheel drive, while the off-road forklift is four-wheel drive.

2. Ordinary forklift truck chassis is low, while off-road forklift truck chassis.

3. Ordinary forklift trucks can only work on the flat road surface, while off-road forklift trucks can work on the ordinary road surface, and can also work on the rugged road on the mountain road, and the tire grip is strong and does not slip.

4. The speed of off-road forklifts is higher than that of ordinary forklifts, and it has been developed to 40km/h, and its maneuverability is obvious.

5. Off-road forklift truck engine power is large, using all-wheel drive and off-road tires.

6. The off-road forklift can drive on Chenling, mountain, beachhead, sand, snow, ice and muddy roads, with good off-road performance.
